> For the complete documentation index, see [llms.txt](https://docs.collibra.com/llms.txt). Markdown versions of documentation pages are available by appending `.md` to page URLs; this page is available as [Markdown](https://docs.collibra.com/data-quality-self-hosted/installation/installing-data-quality-observability-self-hosted-on-self-hosted-kubernetes/deploy-on-self-hosted-kubernetes/configure-custom-jdbc-data-source-drivers.md). # Configure custom JDBC data source drivers This section shows you how to set up persistent external volumes on existing cloud native deployments of Collibra DQ to support the use of custom JDBC data source drivers. {% tabs %} {% tab title="Configure NFS" %} ## Steps {% stepper %} {% step %} Create a Persistent Volume (PV) and a Persistent Volume Claim (PVC) in the same Kubernetes cluster namespace where your cloud native deployment of Collibra DQ is running with `ReadWriteMany` access mode, as shown in the following example: ``` apiVersion: v1 kind: PersistentVolume metadata: name: nfs-pv spec: capacity: storage: 10Gi accessModes: - ReadWriteMany nfs: server: nfs-server.nfs.svc.cluster.local path: "/" --- kind: PersistentVolumeClaim apiVersion: v1 metadata: name: nfs-pvc spec: accessModes: - ReadWriteMany storageClassName: "" resources: requests: storage: 10Gi ``` {% hint style="success" %} You can choose any storage class that supports ReadWriteMany access mode only. {% endhint %} {% endstep %} {% step %} Patch the existing DQ Web and Agent StatefulSets with an additional Volume Mount, as shown in the following example: ``` spec: volumes: - name: owldq-ext-jdbc-jars persistentVolumeClaim: claimName: nfs-pvc ... ... containers: - volumeMounts: - name: owldq-ext-jdbc-jars mountPath: /opt/owl/drivers/ext ``` {% endstep %} {% step %} From the Connections page, click **Add** on the **Generic JDBC Connection** tile.\ :chevrons-right: The **New JDBC Conection** modal appears. {% endstep %} {% step %} Enter the required information. {% endstep %} {% step %} Click the folder icon in the **Driver Location** option.\ :chevrons-right: The **Add Driver** modal appears. {% endstep %} {% step %} Click **Choose File** and select the JAR file to upload. {% endstep %} {% step %} Enter a one-word directory name to store the driver, for example, *ext*. {% endstep %} {% step %} Select `/opt/owl/drivers/ext` under **Driver Directories** to upload your driver to that location, as shown in the image below. adding a custom driver {% endstep %} {% step %} Click **Upload**.\ :chevrons-right: A success message appears when your driver is successfully added. {% hint style="info" %} Uploads from DQ Web only work if the PVC's storageclass supports the fsGroup security context of Kubernetes. If the fsGroup security context is not supported, create a temporary dummy pod running as a root user with the PVC mounted, and copy the required JDBC jars to the mount location with 544 permissions. {% endhint %} {% endstep %} {% step %} Go to the **Remote Agent** section of the Admin Console and click the pencil icon to edit your agent.\ :chevrons-right: The **Edit Agent** modal appears. {% endstep %} {% step %} Add the following properties to the **Free Form (Appended)** option, as shown in the following example: ``` -conf spark.kubernetes.driver.podTemplateFile=local:///opt/owl/config/k8s-driver-template.yml,spark.kubernetes.executor.podTemplateFile=local:///opt/owl/config/k8s-executor-template.yml,spark.kubernetes.executor.volumes.persistentVolumeClaim.nfs-pv.options.claimName=nfs-pvc,spark.kubernetes.executor.volumes.persistentVolumeClaim.nfs-pv.options.sizeLimit=10Gi,spark.kubernetes.executor.volumes.persistentVolumeClaim.nfs-pv.mount.path=/opt/owl/drivers/ext,spark.kubernetes.executor.volumes.persistentVolumeClaim.nfs-pv.mount.readOnly=false,spark.kubernetes.driver.volumes.persistentVolumeClaim.nfs-pv.options.claimName=nfs-pvc,spark.kubernetes.driver.volumes.persistentVolumeClaim.nfs-pv.options.sizeLimit=10Gi,spark.kubernetes.driver.volumes.persistentVolumeClaim.nfs-pv.mount.path=/opt/owl/drivers/ext,spark.kubernetes.driver.volumes.persistentVolumeClaim.nfs-pv.mount.readOnly=false ``` {% hint style="info" %} The pod templates induce security context to the Spark driver and executor pods, which allows you to mount the PVC dynamically. You can also download the template file and host it in your own public space. {% endhint %} {% endstep %} {% step %} Click **Save**. {% endstep %} {% step %} Go to the **Connections** page to start using your new custom JDBC data source driver. {% endstep %} {% endstepper %} {% endtab %} {% tab title="Configure EFS" %} ## Steps {% stepper %} {% step %} Install the EFS Container Storage Interface (CSI) Driver on your cluster. {% endstep %} {% step %} Create a Persistent Volume (PV) and a Persistent Volume Claim (PVC) in the same Kubernetes cluster namespace where your cloud native deployment of Collibra DQ is running with `ReadWriteMany` access mode, as shown in the following example: ``` apiVersion: storage.k8s.io/v1 kind: StorageClass metadata: name: efs-sc provisioner: efs.csi.aws.com reclaimPolicy: Delete volumeBindingMode: Immediate --- apiVersion: v1 kind: PersistentVolume metadata: name: efs-pv spec: capacity: storage: 5Gi volumeMode: Filesystem accessModes: - ReadWriteMany storageClassName: efs-sc persistentVolumeReclaimPolicy: Retain csi: driver: efs.csi.aws.com volumeHandle: fs-e8a95a42 --- apiVersion: v1 kind: PersistentVolumeClaim metadata: name: efs-claim spec: accessModes: - ReadWriteMany storageClassName: efs-sc resources: requests: storage: 5Gi ``` {% hint style="success" %} You can choose any storage class that supports ReadWriteMany access mode only. {% endhint %} {% endstep %} {% step %} Patch the existing DQ Web and Agent StatefulSets with an additional Volume Mount, as shown in the following example: ``` spec: volumes: - name: owldq-ext-jdbc-jars persistentVolumeClaim: claimName: efs-claim ... ... containers: - volumeMounts: - name: owldq-ext-jdbc-jars mountPath: /opt/owl/drivers/ext ``` {% endstep %} {% step %} From the Connections page, click **Add** on the **Generic JDBC Connection** tile.\ :chevrons-right: The **New JDBC Conection** modal appears. {% endstep %} {% step %} Enter the required information. {% endstep %} {% step %} Click the folder icon in the **Driver Location** option.\ :chevrons-right: The **Add Driver** modal appears. {% endstep %} {% step %} Click **Choose File** and select the JAR file to upload. {% endstep %} {% step %} Enter a one-word directory name to store the driver, for example, *ext*. {% endstep %} {% step %} Select `/opt/owl/drivers/ext` under **Driver Directories** to upload your driver to that location, as shown in the image below. adding a custom driver {% endstep %} {% step %} Click **Upload**.\ :chevrons-right: A success message appears when your driver is successfully added. {% hint style="info" %} Uploads from DQ Web only work if the PVC's storageclass supports the fsGroup security context of Kubernetes. If the fsGroup security context is not supported, create a temporary dummy pod running as a root user with the PVC mounted, and copy the required JDBC jars to the mount location with 544 permissions. {% endhint %} {% endstep %} {% step %} Go to the **Remote Agent** section of the Admin Console and click the pencil icon to edit your agent.\ :chevrons-right: The **Edit Agent** modal appears. {% endstep %} {% step %} Add the following properties to the **Free Form (Appended)** option, as shown in the following example: ``` -conf spark.kubernetes.driver.podTemplateFile=local:///opt/owl/config/k8s-driver-template.yml,spark.kubernetes.executor.podTemplateFile=local:///opt/owl/config/k8s-executor-template.yml,spark.kubernetes.executor.volumes.persistentVolumeClaim.efs-pv.options.claimName=efs-claim,spark.kubernetes.executor.volumes.persistentVolumeClaim.efs-pv.options.sizeLimit=10Gi,spark.kubernetes.executor.volumes.persistentVolumeClaim.efs-pv.mount.path=/opt/owl/drivers/ext,spark.kubernetes.executor.volumes.persistentVolumeClaim.efs-pv.mount.readOnly=false,spark.kubernetes.driver.volumes.persistentVolumeClaim.efs-pv.options.claimName=efs-claim,spark.kubernetes.driver.volumes.persistentVolumeClaim.efs-pv.options.sizeLimit=10Gi,spark.kubernetes.driver.volumes.persistentVolumeClaim.efs-pv.mount.path=/opt/owl/drivers/ext,spark.kubernetes.driver.volumes.persistentVolumeClaim.efs-pv.mount.readOnly=false ``` {% hint style="info" %} The pod templates induce security context to the Spark driver and executor pods, which allows you to mount the PVC dynamically. You can also download the template file and host it in your own public space. {% endhint %} {% endstep %} {% step %} Click **Save**. {% endstep %} {% step %} Go to the **Connections** page to start using your new custom JDBC data source driver. {% endstep %} {% endstepper %} {% endtab %} {% endtabs %}
